316 Mineral Stainless Steel Wedge Wire Screen Filter Mesh Pipe For Separation
Wedge screen filter Introduction:
Wedge screen filter are made when special shaped working wires are simultaneously wound around the screw and welded to a ribbon wire placed along the tube. This technology allows the production of wedge-shaped mesh screens when very high clearance accuracy and mesh resistance are required. Due to the use of the latest welding technology, we can obtain the distance between different load lines, very precise and repeatable clearance, so can produce the screen according to the customer's special requirements.
| No. | (mm)TYPE | OD (mm) | ID(mm) | SuppoTt wiTe NumbeT | Filter diTection |
| 1 | STD25.4 | 25.4 | 18.6 | 12 | FOTI |
| 2 | STD 33 | 33 | 24 | 8 | FOTI |
| 3 | STD 37 | 37 | 28 | 8 | FOTI |
| 4 | STD 40 | 40 | 31 | 8/10 | FOTI/FITO |
| 5 | STD 45 | 45 | 36 | 10/12 | FOTI/FITO |
| 6 | STD 48 | 48 | 38 | 12 | FOTI/FITO |
| 7 | STD 60 | 60 | 51 | 12 | FOTI/FITO |
| 8 | STD 70 | 70 | 61 | 12/18 | FOTI/FITO |
| 9 | STD 85 | 85 | 76 | 18 | FOTI/FITO |
| 10 | STD 110 | 110 | 101 | 24 | FOTI/FITO |
| 11 | STD120 | 120 | 111 | 24 | FOTI/FITO |
Characteristic:
1. A continuous slot launching which significantly increases the provided start place, therefore supplying higher access to the h2o showing location
2. A V-created consumer user profile cord which gets rid of blocking and helps make particular an ongoing flow.
3. A standard and successful well development due to the continuing port launching.
4. Step ladder-like cable welded watches have got a highly effective structure and open up location, as well as accurate slot sizing.
5. Stage step ladder-like cord welded exhibit displays hold the highlights of easy backwashing, go very far, protection and dependability in addition to lessened substantial selling price.
The Advantages:
Maximazing flow costs :
With regards to exhibit display screens of equal length, diameter and port dimensions, activity prices through V-designed well displays can beThree occasions beyond connection-harbour screensNine circumstances greater than slotted casing
Lower blocking harbour :
Steady-port well screen monitors have V-shaped prospects that narrowest in the outside encounter and broaden inwardly, thus, extra-large debris are retained outside the display and dust transferring from the narrow outside opening can enter in the screen.
Decrease in doing work selling price :
Through a Continous-slot well screen, price savings can be accomplished in pumping fees. Lowered through-dock velocities propose that strain droplets are decreased, therefore :
Drawdowns are reduced, Significantly less potential is essential for doing work, Flow prices are increased, Much less fine inpurity in the liquid lowers put on within the pumps.
Application:
The details of profiles:
Packages
The Delivery
